Separator Filter
Separator Filter K56-B
1. Endless gasket to provide excellent air tightness
2. 100% factory inspection
3. Wedge shaped pleat design to prevent the filter media from damage
4. Big filtration area, big air flow, high efficiency
5. 100% humidity resistance
6. Even wind speed, big dust holding capacity
7. High versatility
2. 100% factory inspection
3. Wedge shaped pleat design to prevent the filter media from damage
4. Big filtration area, big air flow, high efficiency
5. 100% humidity resistance
6. Even wind speed, big dust holding capacity
7. High versatility
Product Details
-
Low resistance
-
Low run cost
-
Light weight
-
Convenient installation and replacement
-
Long life-span
-
100% factory inspection
-
Good sealing
-
Super high efficiency
Specification
-
Micro glass fiber
-
Extruded aluminum / Sheet aluminum /Galvanized /Stainless steel / MDF
-
Two-component polyurethane glue
-
PU foam gasket / EVA / EPDM
-
Offset paper / Aluminum foil
-
80 96 120 150 220 292 305
-
Offset paper-50℃ Aluminum foil-100℃
-
100%
Product Specification
| Model NO. | Actual SizeHxWxD(mm) | Air Flow(m3/h) | Media AreaFlow (m2) | Velocity(m/s) |
|---|---|---|---|---|
| K56-B-001 | 594×287×292 | 1000 | 6.04 | 1.63 |
| K56-B-002 | 594×594×292 | 2000 | 12.5 | 1.57 |
| K56-B-003 | 594×287×150 | 500 | 2.75 | 0.81 |
| K56-B-004 | 594×594×150 | 1000 | 5.7 | 0.79 |
| K56-B-005 | 594×287×292 | 1000 | 6.04 | 1.63 |
| K56-B-006 | 594×594×292 | 2000 | 12.5 | 1.57 |
